Xin You Ya Bearing have a wide variety of angular contact ball bearings in our stock. They are:
Brand: SKF, NSK, FAG, NTN
single row angular contact ball bearings: 70, 718, 719, 72, 72, 74 series
double row angular contact ball bearings: 32 (or 52), 33 (or 53) series
four-point contact ball bearings: QJ series
30/5-B-2Z-TVH -Angular contact ball bearings
FAG 30/5-B-2Z-TVH Angular contact ball bearings, In stock, Dimensions: 5 mm x 14 mm x 7 mm, Basic dynamic load rating: 1.78 kN, Static load rating: 0.94 kN.
- Brand: FAG
- Inside Diameter: 5 mm
- Outside Diameter: 14 mm
- Width: 7 mm
- Basic dynamic load rating: 1.78 kN
- Basic static load rating: 0.94 kN
3806-B-2RS-TVH -Angular contact ball bearings
FAG 3806-B-2RS-TVH Angular contact ball bearings, In stock, Dimensions: 30 mm x 42 mm x 10 mm, Basic dynamic load rating: 6.1 kN, Static load rating: 6 kN.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 42 mm
- Width: 10 mm
- Basic dynamic load rating: 6.1 kN
- Basic static load rating: 6 kN
3801-B-2RS-TVH -Angular contact ball bearings
FAG 3801-B-2RS-TVH Angular contact ball bearings, In stock, Dimensions: 12 mm x 21 mm x 7 mm, Basic dynamic load rating: 2.15 kN, Static load rating: 1.52 kN.
- Brand: FAG
- Inside Diameter: 12 mm
- Outside Diameter: 21 mm
- Width: 7 mm
- Basic dynamic load rating: 2.15 kN
- Basic static load rating: 1.52 kN
3217-B-2RS-TVH -Angular contact ball bearings
FAG 3217-B-2RS-TVH Angular contact ball bearings, In stock, Dimensions: 85 mm x 150 mm x 49.2 mm, Basic dynamic load rating: 135 kN, Static load rating: 127 kN.
- Brand: FAG
- Inside Diameter: 85 mm
- Outside Diameter: 150 mm
- Width: 49.2 mm
- Basic dynamic load rating: 135 kN
- Basic static load rating: 127 kN
3313-BD-XL -Angular contact ball bearings
FAG 3313-BD-XL Angular contact ball bearings, In stock, Dimensions: 65 mm x 140 mm x 58.7 mm, Basic dynamic load rating: 150 kN, Static load rating: 119 kN.
- Brand: FAG
- Inside Diameter: 65 mm
- Outside Diameter: 140 mm
- Width: 58.7 mm
- Basic dynamic load rating: 150 kN
- Basic static load rating: 119 kN
3311-BD-XL -Angular contact ball bearings
FAG 3311-BD-XL Angular contact ball bearings, In stock, Dimensions: 55 mm x 120 mm x 49.2 mm, Basic dynamic load rating: 116 kN, Static load rating: 88 kN.
- Brand: FAG
- Inside Diameter: 55 mm
- Outside Diameter: 120 mm
- Width: 49.2 mm
- Basic dynamic load rating: 116 kN
- Basic static load rating: 88 kN
3310-BD-XL-TVH -Angular contact ball bearings
FAG 3310-BD-XL-TVH Angular contact ball bearings, In stock, Dimensions: 50 mm x 110 mm x 44.4 mm, Basic dynamic load rating: 93 kN, Static load rating: 70 kN.
- Brand: FAG
- Inside Diameter: 50 mm
- Outside Diameter: 110 mm
- Width: 44.4 mm
- Basic dynamic load rating: 93 kN
- Basic static load rating: 70 kN
3310-BD-XL -Angular contact ball bearings
FAG 3310-BD-XL Angular contact ball bearings, In stock, Dimensions: 50 mm x 110 mm x 44.4 mm, Basic dynamic load rating: 93 kN, Static load rating: 70 kN.
- Brand: FAG
- Inside Diameter: 50 mm
- Outside Diameter: 110 mm
- Width: 44.4 mm
- Basic dynamic load rating: 93 kN
- Basic static load rating: 70 kN
3309-BD-XL -Angular contact ball bearings
FAG 3309-BD-XL Angular contact ball bearings, In stock, Dimensions: 45 mm x 100 mm x 39.7 mm, Basic dynamic load rating: 72 kN, Static load rating: 54 kN.
- Brand: FAG
- Inside Diameter: 45 mm
- Outside Diameter: 100 mm
- Width: 39.7 mm
- Basic dynamic load rating: 72 kN
- Basic static load rating: 54 kN
3307-BD-XL -Angular contact ball bearings
FAG 3307-BD-XL Angular contact ball bearings, In stock, Dimensions: 35 mm x 80 mm x 34.9 mm, Basic dynamic load rating: 55 kN, Static load rating: 36.5 kN.
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 80 mm
- Width: 34.9 mm
- Basic dynamic load rating: 55 kN
- Basic static load rating: 36.5 kN
3306-BD-XL -Angular contact ball bearings
FAG 3306-BD-XL Angular contact ball bearings, In stock, Dimensions: 30 mm x 72 mm x 30.2 mm, Basic dynamic load rating: 43 kN, Static load rating: 29.5 kN.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 72 mm
- Width: 30.2 mm
- Basic dynamic load rating: 43 kN
- Basic static load rating: 29.5 kN
3305-BD-XL -Angular contact ball bearings
FAG 3305-BD-XL Angular contact ball bearings, In stock, Dimensions: 25 mm x 62 mm x 25.4 mm, Basic dynamic load rating: 31.5 kN, Static load rating: 21 kN.
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 62 mm
- Width: 25.4 mm
- Basic dynamic load rating: 31.5 kN
- Basic static load rating: 21 kN
3304-BD-XL -Angular contact ball bearings
FAG 3304-BD-XL Angular contact ball bearings, In stock, Dimensions: 20 mm x 52 mm x 22.2 mm, Basic dynamic load rating: 24.6 kN, Static load rating: 15.9 kN.
- Brand: FAG
- Inside Diameter: 20 mm
- Outside Diameter: 52 mm
- Width: 22.2 mm
- Basic dynamic load rating: 24.6 kN
- Basic static load rating: 15.9 kN
3213-BD-XL -Angular contact ball bearings
FAG 3213-BD-XL Angular contact ball bearings, In stock, Dimensions: 65 mm x 120 mm x 38.1 mm, Basic dynamic load rating: 86 kN, Static load rating: 77 kN.
- Brand: FAG
- Inside Diameter: 65 mm
- Outside Diameter: 120 mm
- Width: 38.1 mm
- Basic dynamic load rating: 86 kN
- Basic static load rating: 77 kN
3212-BD-XL-TVH -Angular contact ball bearings
FAG 3212-BD-XL-TVH Angular contact ball bearings, In stock, Dimensions: 60 mm x 110 mm x 36.5 mm, Basic dynamic load rating: 75 kN, Static load rating: 64 kN.
- Brand: FAG
- Inside Diameter: 60 mm
- Outside Diameter: 110 mm
- Width: 36.5 mm
- Basic dynamic load rating: 75 kN
- Basic static load rating: 64 kN
3212-BD-XL -Angular contact ball bearings
FAG 3212-BD-XL Angular contact ball bearings, In stock, Dimensions: 60 mm x 110 mm x 36.5 mm, Basic dynamic load rating: 75 kN, Static load rating: 64 kN.
- Brand: FAG
- Inside Diameter: 60 mm
- Outside Diameter: 110 mm
- Width: 36.5 mm
- Basic dynamic load rating: 75 kN
- Basic static load rating: 64 kN
3211-BD-XL -Angular contact ball bearings
FAG 3211-BD-XL Angular contact ball bearings, In stock, Dimensions: 55 mm x 100 mm x 33.3 mm, Basic dynamic load rating: 61 kN, Static load rating: 51 kN.
- Brand: FAG
- Inside Diameter: 55 mm
- Outside Diameter: 100 mm
- Width: 33.3 mm
- Basic dynamic load rating: 61 kN
- Basic static load rating: 51 kN
3210-BD-XL-TVH -Angular contact ball bearings
FAG 3210-BD-XL-TVH Angular contact ball bearings, In stock, Dimensions: 50 mm x 90 mm x 30.2 mm, Basic dynamic load rating: 53 kN, Static load rating: 44 kN.
- Brand: FAG
- Inside Diameter: 50 mm
- Outside Diameter: 90 mm
- Width: 30.2 mm
- Basic dynamic load rating: 53 kN
- Basic static load rating: 44 kN
3207-BD-XL -Angular contact ball bearings
FAG 3207-BD-XL Angular contact ball bearings, In stock, Dimensions: 35 mm x 72 mm x 27 mm, Basic dynamic load rating: 0 kN, Static load rating: 0 kN.
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 72 mm
- Width: 27 mm
- Basic dynamic load rating: 0 kN
- Basic static load rating: 0 kN
3206-BD-XL -Angular contact ball bearings
FAG 3206-BD-XL Angular contact ball bearings, In stock, Dimensions: 30 mm x 62 mm x 23.8 mm, Basic dynamic load rating: 31 kN, Static load rating: 22.2 kN.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 62 mm
- Width: 23.8 mm
- Basic dynamic load rating: 31 kN
- Basic static load rating: 22.2 kN
