Miniature ball bearings can be divided into two basic types, deep groove and angular contact. Miniature ball bearings are useful in a wide variety of applications where space is limited, such as automotive, electrical and medical devices.
FR1810 -Miniature bearing
NSK FR1810 Miniature bearing, In stock, Dimensions: 7.938 mm x 12.7 mm x 3.967 mm, Basic dynamic load rating: 0.54 kN, Static load rating: 0.276 kN.
- Brand: NSK
- Inside Diameter: 7.938 mm
- Outside Diameter: 12.7 mm
- Width: 3.967 mm
- Basic dynamic load rating: 0.54 kN
- Basic static load rating: 0.276 kN
FR4-Miniature bearing
NSK FR4 Miniature bearing, In stock, Dimensions: 6.35 mm x 15.875 mm x 4.978 mm, Basic dynamic load rating: 1.48 kN, Static load rating: 0.615 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 15.875 mm
- Width: 4.978 mm
- Basic dynamic load rating: 1.48 kN
- Basic static load rating: 0.615 kN
FR188 -Miniature bearing
NSK FR188 Miniature bearing, In stock, Dimensions: 6.35 mm x 12.7 mm x 3.175 mm, Basic dynamic load rating: 1.08 kN, Static load rating: 0.44 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 12.7 mm
- Width: 3.175 mm
- Basic dynamic load rating: 1.08 kN
- Basic static load rating: 0.44 kN
FR168 -Miniature bearing
NSK FR168 Miniature bearing, In stock, Dimensions: 6.35 mm x 9.525 mm x 3.175 mm, Basic dynamic load rating: 0.375 kN, Static load rating: 0.173 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 9.525 mm
- Width: 3.175 mm
- Basic dynamic load rating: 0.375 kN
- Basic static load rating: 0.173 kN
FR3 -Miniature bearing
NSK FR3 Miniature bearing, In stock, Dimensions: 4.762 mm x 12.7 mm x 4.978 mm, Basic dynamic load rating: 1.3 kN, Static load rating: 0.485 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 12.7 mm
- Width: 4.978 mm
- Basic dynamic load rating: 1.3 kN
- Basic static load rating: 0.485 kN
FR166 -Miniature bearing
NSK FR166 Miniature bearing, In stock, Dimensions: 4.762 mm x 9.525 mm x 3.175 mm, Basic dynamic load rating: 0.71 kN, Static load rating: 0.27 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 9.525 mm
- Width: 3.175 mm
- Basic dynamic load rating: 0.71 kN
- Basic static load rating: 0.27 kN
FR156 -Miniature bearing
NSK FR156 Miniature bearing, In stock, Dimensions: 4.762 mm x 7.938 mm x 2.779 mm, Basic dynamic load rating: 0.36 kN, Static load rating: 0.149 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 7.938 mm
- Width: 2.779 mm
- Basic dynamic load rating: 0.36 kN
- Basic static load rating: 0.149 kN
FR155 -Miniature bearing
NSK FR155 Miniature bearing, In stock, Dimensions: 3.967 mm x 7.938 mm x 2.779 mm, Basic dynamic load rating: 0.36 kN, Static load rating: 0.149 kN.
- Brand: NSK
- Inside Diameter: 3.967 mm
- Outside Diameter: 7.938 mm
- Width: 2.779 mm
- Basic dynamic load rating: 0.36 kN
- Basic static load rating: 0.149 kN
FR4-Miniature bearing
NSK FR4 Miniature bearing, In stock, Dimensions: 6.35 mm x 15.875 mm x 4.978 mm, Basic dynamic load rating: 1.48 kN, Static load rating: 0.615 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 15.875 mm
- Width: 4.978 mm
- Basic dynamic load rating: 1.48 kN
- Basic static load rating: 0.615 kN
FR3ZZ -Miniature bearing
NSK FR3ZZ Miniature bearing, In stock, Dimensions: 4.762 mm x 12.7 mm x 4.978 mm, Basic dynamic load rating: 1.3 kN, Static load rating: 0.485 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 12.7 mm
- Width: 4.978 mm
- Basic dynamic load rating: 1.3 kN
- Basic static load rating: 0.485 kN
FR155ZZS -Miniature bearing
NSK FR155ZZS Miniature bearing, In stock, Dimensions: 3.967 mm x 7.938 mm x 3.175 mm, Basic dynamic load rating: 0.36 kN, Static load rating: 0.149 kN.
- Brand: NSK
- Inside Diameter: 3.967 mm
- Outside Diameter: 7.938 mm
- Width: 3.175 mm
- Basic dynamic load rating: 0.36 kN
- Basic static load rating: 0.149 kN
FR2-6ZZS -Miniature bearing
NSK FR2-6ZZS Miniature bearing, In stock, Dimensions: 3.175 mm x 9.525 mm x 3.571 mm, Basic dynamic load rating: 0.64 kN, Static load rating: 0.225 kN.
- Brand: NSK
- Inside Diameter: 3.175 mm
- Outside Diameter: 9.525 mm
- Width: 3.571 mm
- Basic dynamic load rating: 0.64 kN
- Basic static load rating: 0.225 kN
FR2-5ZZ -Miniature bearing
NSK FR2-5ZZ Miniature bearing, In stock, Dimensions: 3.175 mm x 7.938 mm x 3.571 mm, Basic dynamic load rating: 0.56 kN, Static load rating: 0.179 kN.
- Brand: NSK
- Inside Diameter: 3.175 mm
- Outside Diameter: 7.938 mm
- Width: 3.571 mm
- Basic dynamic load rating: 0.56 kN
- Basic static load rating: 0.179 kN
FR0ZZS -Miniature bearing
NSK FR0ZZS Miniature bearing, In stock, Dimensions: 1.191 mm x 3.967 mm x 2.38 mm, Basic dynamic load rating: 0.138 kN, Static load rating: 0.035 kN.
- Brand: NSK
- Inside Diameter: 1.191 mm
- Outside Diameter: 3.967 mm
- Width: 2.38 mm
- Basic dynamic load rating: 0.138 kN
- Basic static load rating: 0.035 kN
R4-Miniature bearing
NSK R4 Miniature bearing, In stock, Dimensions: 6.35 mm x 15.875 mm x 4.978 mm, Basic dynamic load rating: 1.61 kN, Static load rating: 0.66 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 15.875 mm
- Width: 4.978 mm
- Basic dynamic load rating: 1.61 kN
- Basic static load rating: 0.66 kN
R168 -Miniature bearing
NSK R168 Miniature bearing, In stock, Dimensions: 6.35 mm x 9.525 mm x 3.175 mm, Basic dynamic load rating: 0.375 kN, Static load rating: 0.173 kN.
- Brand: NSK
- Inside Diameter: 6.35 mm
- Outside Diameter: 9.525 mm
- Width: 3.175 mm
- Basic dynamic load rating: 0.375 kN
- Basic static load rating: 0.173 kN
R3 -Miniature bearing
NSK R3 Miniature bearing, In stock, Dimensions: 4.762 mm x 12.7 mm x 3.967 mm, Basic dynamic load rating: 1.3 kN, Static load rating: 0.485 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 12.7 mm
- Width: 3.967 mm
- Basic dynamic load rating: 1.3 kN
- Basic static load rating: 0.485 kN
R166 -Miniature bearing
NSK R166 Miniature bearing, In stock, Dimensions: 4.762 mm x 9.525 mm x 3.175 mm, Basic dynamic load rating: 0.71 kN, Static load rating: 0.27 kN.
- Brand: NSK
- Inside Diameter: 4.762 mm
- Outside Diameter: 9.525 mm
- Width: 3.175 mm
- Basic dynamic load rating: 0.71 kN
- Basic static load rating: 0.27 kN
R2 -Miniature bearing
NSK R2 Miniature bearing, In stock, Dimensions: 3.175 mm x 9.525 mm x 3.967 mm, Basic dynamic load rating: 0.63 kN, Static load rating: 0.218 kN.
- Brand: NSK
- Inside Diameter: 3.175 mm
- Outside Diameter: 9.525 mm
- Width: 3.967 mm
- Basic dynamic load rating: 0.63 kN
- Basic static load rating: 0.218 kN
R2-6 -Miniature bearing
NSK R2-6 Miniature bearing, In stock, Dimensions: 3.175 mm x 9.525 mm x 2.779 mm, Basic dynamic load rating: 0.64 kN, Static load rating: 0.225 kN.
- Brand: NSK
- Inside Diameter: 3.175 mm
- Outside Diameter: 9.525 mm
- Width: 2.779 mm
- Basic dynamic load rating: 0.64 kN
- Basic static load rating: 0.225 kN
