FAG 7318-B-JP Angular contact ball bearings
Also known as : 7318-B-JP, 7318BECBY
- Inside Diameter: 90 mm
- Outside Diameter: 190 mm
- Width: 43 mm
- Basic dynamic load rating: 180 kN
- Basic static load rating: 155 kN
FAG 7318-B-JP
FAG 7318-B-JP details
| model | 7318-B-JP |
|---|---|
| d | 90 mm |
| D | 190 mm |
| B | 43 mm |
| a | 80 mm |
| D1 | 152.4 mm |
| Da max | 176 mm |
| Db max | 183 mm |
| d1 | 130.1 mm |
| da min | 104 mm |
| r1 min | 1.1 mm |
| ra max | 2.5 mm |
| ra1 max | 1 mm |
| rmin | 3 mm |
| Contact angle | 40° |
| Cr | 180000 N |
| C0r | 155000 N |
| Limiting speed | 4200 1/min |
| Reference speed | 3900 1/min |
| Cur | 8800 N Fatigue limit load, radial |
| mass | 5.14 kg |
FAG 7318-B-JP bearing cross reference
30/5-B-2Z-TVH
90 mmx 190 mmx 43 mm
3806-B-2RS-TVH
90 mmx 190 mmx 43 mm
3801-B-2RS-TVH
90 mmx 190 mmx 43 mm
3217-B-2RS-TVH
90 mmx 190 mmx 43 mm
3313-BD-XL
90 mmx 190 mmx 43 mm
3311-BD-XL
90 mmx 190 mmx 43 mm
3310-BD-XL-TVH
90 mmx 190 mmx 43 mm
3310-BD-XL
90 mmx 190 mmx 43 mm
3309-BD-XL
90 mmx 190 mmx 43 mm
3307-BD-XL
90 mmx 190 mmx 43 mm
3306-BD-XL
90 mmx 190 mmx 43 mm
