TIMKEN 301K

TIMKEN 301K Deep groove ball bearings

Also known as : 301K

Inside Diameter: 12 mm
Outside Diameter: 37 mm
Width: 12 mm
Basic dynamic load rating: 9.4 kN
Basic static load rating: 3.62 kN

TIMKEN 301K

TIMKEN 301K details

Bearing Number	301K
Brand	TIMKEN
Type	Deep groove ball bearings
Design Units	METRIC
Ball Type	Steel
Bearing Weight	0.064 Kg 0.14 lb
d - Bore	12.000 mm 0.4724 in
D - Outer Diameter	37.000 mm 1.4567 in
Bearing Width	12.000 mm 0.4724 in
do - Ball Diameter	7.143800 mm 0.281250 in
Ce - Dynamic Radial Rating¹	9400 N 2120 lbf
C0 - Static Radial Rating	3620 N 815 lbf
Limiting Speed (Grease)	12250 rpm
Limiting Speed (Oil)	14290 rpm
R - Inner Ring "To Clear" Radius²	1.000 mm 0.039 in
r - Outer Ring "To Clear" Radius³	1.000 mm 0.039 in
da - Inner Ring Backing Diameter	16.000 mm 0.630 in
Da - Outer Ring Backing Diameter	31.000 mm 1.220 in

TIMKEN 301K bearing cross reference

302K
12 mmx 37 mmx 12 mm

301K
12 mmx 37 mmx 12 mm

62207-2RS-C3
12 mmx 37 mmx 12 mm

62306-2RS-C3
12 mmx 37 mmx 12 mm

63005-2RS-C3
12 mmx 37 mmx 12 mm

62205-2RS-C3
12 mmx 37 mmx 12 mm

62304-2RS-C3
12 mmx 37 mmx 12 mm

62204-2RS-C3
12 mmx 37 mmx 12 mm

63003-2RS-C3
12 mmx 37 mmx 12 mm

62303-2RS-C3
12 mmx 37 mmx 12 mm

63002-2RS-C3
12 mmx 37 mmx 12 mm

62302-2RS-C3
12 mmx 37 mmx 12 mm
