TIMKEN 216W

TIMKEN 216W Deep groove ball bearings

Also known as : 216W

Inside Diameter: 80 mm
Outside Diameter: 140 mm
Width: 26 mm
Basic dynamic load rating: 114 kN
Basic static load rating: 90.6 kN

TIMKEN 216W

TIMKEN 216W details

Bearing Number	216W
Brand	TIMKEN
Type	Deep groove ball bearings
Design Units	METRIC
Ball Type	Steel
Bearing Weight	1.633 Kg 3.60 lb
d - Bore	80.000 mm 3.1496 in
D - Outer Diameter	140.000 mm 5.5118 in
Bearing Width	26.000 mm 1.0236 in
do - Ball Diameter	19.05000 mm 0.75000 in
Ce - Dynamic Radial Rating¹	114000 N 26000 lbf
C0 - Static Radial Rating	90600 N 20400 lbf
Limiting Speed (Grease)	2270 rpm
Limiting Speed (Oil)	2730 rpm
R - Inner Ring "To Clear" Radius²	2.000 mm 0.079 in
r - Outer Ring "To Clear" Radius³	2.000 mm 0.079 in
da - Inner Ring Backing Diameter	90.200 mm 3.550 in
Da - Outer Ring Backing Diameter	130.000 mm 5.120 in

TIMKEN 216W bearing cross reference

302K
80 mmx 140 mmx 26 mm

301K
80 mmx 140 mmx 26 mm

62207-2RS-C3
80 mmx 140 mmx 26 mm

62306-2RS-C3
80 mmx 140 mmx 26 mm

63005-2RS-C3
80 mmx 140 mmx 26 mm

62205-2RS-C3
80 mmx 140 mmx 26 mm

62304-2RS-C3
80 mmx 140 mmx 26 mm

62204-2RS-C3
80 mmx 140 mmx 26 mm

63003-2RS-C3
80 mmx 140 mmx 26 mm

62303-2RS-C3
80 mmx 140 mmx 26 mm

63002-2RS-C3
80 mmx 140 mmx 26 mm

62302-2RS-C3
80 mmx 140 mmx 26 mm
