NSK N232M Cylindrical roller bearing
Also known as : N232M, N232M
- Inside Diameter: 160 mm
- Outside Diameter: 290 mm
- Width: 48 mm
- Basic dynamic load rating: 430 kN
- Basic static load rating: 570 kN
NSK N232M
NSK N232M details
| NSK No. | N232M |
|---|---|
| d | 160 mm |
| D | 290 mm |
| B | 48 mm |
| rmin. | 3.0 mm |
| r1 min. | 3.0 mm |
| Ew | 255 mm |
| Cr | 430 kN, Basic dynamic Load Ratings |
| C0r | 570 kN, Basic static Load Ratings |
|
Limiting speeds Thermal Reference |
2800 min-1 |
|
Limiting speeds Grease |
2200 min-1 |
|
Limiting speeds Oil |
2600 min-1 |
| Mass | 14.2 kg (approx.) |
NSK N232M bearing cross reference
NN30/500-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3092-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3088-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3084-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3076-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3072-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3064-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3044-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3040-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3034-AS-K-M-SP
160 mmx 290 mmx 48 mm
NN3032-AS-K-M-SP
160 mmx 290 mmx 48 mm
