INA 89326-M Thrust roller bearings
Also known as : 89326-M
- Inside Diameter: 130 mm
- Outside Diameter: 225 mm
- Width: 58 mm
- Basic dynamic load rating: 720 kN
- Basic static load rating: 2700 kN
INA 89326-M
INA 89326-M details
| Number | 89326-M | |
|---|---|---|
| Type | Thrust roller bearings | |
| d | 130 mm | |
| D | 225 mm | |
| T | 58 mm | |
| D1 | 134 mm | |
| Da max | 141 mm | |
| d1 | 225 mm | |
| da min | 220 mm | |
| ra max | 2,1 mm | |
| rmin | 2,1 mm | |
| m | 11,2 kg | Mass |
| Ca | 720000 N | Basic dynamic load rating, axial |
| C0a | 2700000 N | Basic static load rating, axial |
| Cua | 250000 N | Fatigue limit load |
| nG | 1620 1/min | Limiting speed |
| nB | 650 1/min | Reference speed |
| K89326-M | Allocated axial cylindrical roller and cage assembly | |
| GS89326 | Allocated housing locating washer | |
| WS89326 | Allocated shaft locating washer |
INA 89326-M bearing cross reference
81222-TV
130 mmx 225 mmx58 mm
89326-M
130 mmx 225 mmx58 mm
K81217-TV
130 mmx 225 mmx58 mm
K81214-TV
130 mmx 225 mmx58 mm
K81212-TV
130 mmx 225 mmx58 mm
K81211-TV
130 mmx 225 mmx58 mm
K81207-TV
130 mmx 225 mmx58 mm
K81160-M
130 mmx 225 mmx58 mm
K81148-M
130 mmx 225 mmx58 mm
K81144-M
130 mmx 225 mmx58 mm
K81136-M
130 mmx 225 mmx58 mm
