INA K81117-TV Thrust roller bearings
Also known as : K81117-TV
- Inside Diameter: 85 mm
- Outside Diameter: 110 mm
- Width: 7.5 mm
- Basic dynamic load rating: 113 kN
- Basic static load rating: 385 kN
INA K81117-TV
INA K81117-TV details
| Number | K81117-TV | |
|---|---|---|
| Type | Thrust roller bearings | |
| Dc1 | 85 mm | |
| Dc | 110 mm | |
| Dw | 7,5 mm | |
| Ea | 108 mm | |
| Eb | 87 mm | |
| m | 0,118 kg | Mass |
| Ca | 113000 N | Basic dynamic load rating, axial |
| C0a | 385000 N | Basic static load rating, axial |
| Cua | 39000 N | Fatigue limit load |
| nG | 3000 1/min | Limiting speed |
| nB | 1090 1/min | Reference speed |
| GS81117 | Allocated housing locating washer | |
| WS81117 | Allocated shaft locating washer | |
| LS85110 | Allocated bearing washer |
INA K81117-TV bearing cross reference
81222-TV
85 mmx 110 mmx7.5 mm
89326-M
85 mmx 110 mmx7.5 mm
K81217-TV
85 mmx 110 mmx7.5 mm
K81214-TV
85 mmx 110 mmx7.5 mm
K81212-TV
85 mmx 110 mmx7.5 mm
K81211-TV
85 mmx 110 mmx7.5 mm
K81207-TV
85 mmx 110 mmx7.5 mm
K81160-M
85 mmx 110 mmx7.5 mm
K81148-M
85 mmx 110 mmx7.5 mm
K81144-M
85 mmx 110 mmx7.5 mm
K81136-M
85 mmx 110 mmx7.5 mm
